| Performance Specification |
| Standard Capacities |
100, 200 , 300, 400, 500 Kgf |
| Excitation Voltage |
10 VDC- Maximum
15 VDC |
| Nominal Output |
2.0 mV/ V |
| Non - Linearity |
< ±0.025% FSO |
| Hysteresis |
< ±0.02% FSO |
| Non-Repeatability |
< ±0.01% FSO |
| Creep (30 minutes) |
< ±0.03% FSO |
| Zero Balance |
±1.0% FSO |
| Input Resistance |
400 ± 15 Ohms |
| Output Resistance |
350 ± 5 Ohms |
| Insulation Resistance (50 VDC) |
> 1000 Mega
Ohms |
| Cable Length (4 Core Screened) |
500 mm.
Minimum |
| Safe Overload of Rated Capacity |
150% |
| Ultimate Overload of Rated Capacity |
200% |
| Temp. Compensated Range |
0-60 0C |
| Temperature Effect on Output |
< 0.0015% FSO/ 0C |
| Temperature Effect on Zero |
< 0.0020% FSO/ 0C |
| Platter Size |
600mm X 600mm |
| Tightening Torque |
1.5 m.kg. |
| Finish & Construction |
Aluminium
/ Alloy Steel |
| Environmental Protection Class |
IP65 |
